EGO Double Dual Probe Thermostats 55.60012.030

Specifications

• Function: Off
• Attachment switch: -
• Sensor temperature min: -20 ° C
• Sensor temperature max: 140 ° C
• Temperature: 30 - 85/110 ° C
• Working range start: 100 °
• Working range end: 270 °
• Capillary tube length: 870/870 mm
• Insulated capillary tube: 800/800 mm
• Probe diameter: 6/6 mm
• Probe length: 129/94 mm
• Screw connection: -
• Axis diameter: 6 / 4.6 mm
• Axis length: 23 mm
• T max.VDE: 80 ° C
• K-factor over 23 °: 0.19 / 0.30 K / K
