EGO Heating Elements 20.21693.000

Specifications

• Power: 2500 w

• Voltage: 230 v
• Length: 250 mm
• Length 1: 50 mm
• Width 1: 31 mm
• Height 1: 6 mm
• Height 2: 18 mm
• Mounting: rectangular flange with thread bolt
• Connection: male faston 6.3mm horizontal
• Tube diameter: 6,5 mm
• Heating circuits: 1
• Hole distance: 56 mm
• Internal diameter: 179 mm
• External diameter: 192 mm
• Height: 22 mm
• Flange: length 70 mm
• Flange: width 22 mm
• Connection: length 47 mm
• Mounting thread: m5
• Application: Convection heating element
