EGO Thermostat 55.13639.030
Specifications
temperature
max. |
185 °C |
number
of poles |
1 -pole |
function |
1CO |
switching
capacity |
16 A |
probe
diameter |
6 mm |
probe
length |
87 mm |
capillary
pipe length |
2380 mm |
gland
nut |
M9x1 |
shaft
diameter |
ø6x4.6
mm |
operating
temperature range |
97-185
°C |
capillary
pipe length insulated |
700 mm |
shaft
length |
23 mm |
rotation
angle |
270 ° |
outer
switch |
2NO |
version |
with
operation switch |
producer |
EGO |
series |
55.13_ |
shaft position |
upper |
