EGO Thermostat 55.34052.010
Specifications
| Temperature max. | 300 °C |
| Number of poles | 3 -pole |
| Function | 3NO |
| Switching capacity | 16 A |
| Probe diameter | 6 mm |
| Probe length | 131 mm |
| Capillary pipe length | 2000 mm |
| Gland nut | - |
| Shaft diameter | ø6x4.6 mm |
| Operating Temperature range | 100-180 °C |
| Capillary pipe length insulated | 1800 mm |
| Shaft length | 23 mm |
| Rotation angle | 270 ° |
| Producer | EGO |
| Series | 55.34_ |
| Shaft position | upper |
