EGO Thermostat55.19639.800
Specifications
|
temperature max. |
185 °C |
|
number of poles |
1 -pole |
|
function |
1NO |
|
switching
capacity |
15 A |
|
probe diameter |
4 mm |
|
probe length |
229 mm |
|
capillary pipe
length |
2500 mm |
|
gland nut |
- |
|
shaft diameter |
ø6x4.6 mm |
|
operating
temperature range |
90-185 °C |
|
capillary pipe
length insulated |
1200/200 mm |
|
shaft length |
23 mm |
|
shaft position |
upper ° |
|
rotation angle |
270 ° |
|
outer switch |
2NO |
|
version |
with operation switch |
|
producer |
EGO |
|
series |
55.19_ |
