TS320S

Specifications

• Temperature Range: Typically +50°C to +320°C (variants may be available from -30°C to 400°C).
• Electric Rating: 16A or 20A at 250V AC (or 10A at 380V AC).
• Switch Type: Single Pole Double Throw (SPDT) or Single Pole Single Throw (SPST).
• Switch Life Cycle: Rated for 100,000 cycles.
• Sensing Method: Liquid expansion mode.
• Bulb & Capillary: Made of 300 series stainless steel.
• Standard Capillary Length: 1000mm (options available from 250mm to 2000mm).
• Mounting: M4 fixed bracket (28mm center to center).
• Approvals: UL, VDE, CE certified.
